The E10000 toolbox is a gas engine driven, revolving field, alternating current (AC) generator designed to supply electrical power for compatible electrical tools, motors, appliances, and lighting.
The E10000 is an enclosed generator which reduces its output sound levels and provides better protection for control panels. Additionally, there are two lockable compartments for storage of tools and additional hardware and accessories.
The E10000 operates at 120-volt and/or 240-volt, single phase, 60 Hz and will operate devices that require up to 8300 watts continuous and 9130 watts surge.
FEATURES
- 456cc Gasoline Engine
- Circuit Breaker Protection
- Electric Start / Recoil Start
- Steel Sleeve Cylinder
- Copper Windings
- Low Oil Shutdown
WARRANTY
- One Year Equipment Warranty
- Two Year Engine Warranty
SPECIFICATIONS
- Maximum Output: 8300 Continuous, 9130 Surge Watts
- Total Amperage: 34 AMPS
- RPM: 3850 +/- 150
- Receptacles: (2) L5-20 / (1) L5-30 / (1) L14-30 / (1) 14-50R
- Noise Level: 74 dB @ 10′
- Fuel Capacity: 12.3 Gallons
- Single Phase: 60Hz
- Oil Capacity: 32oz. (30wt. SAE)
- Size: L: –32″, W-28″, H-26″
- Net Weight: 290 Lbs.
- Approximate Run Time: 24 Hours at 50% Load
